• Wheels: 17" Argent Painted Steel -inc: painted hub covers/center ornaments
• Tires: LT245/75Rx17E BSW A/S (4) -inc: Spare may not be the same as road tire
• Regular Box Style
• Wheels w/Hub Covers
• Steel Spare Wheel
• Full-Size Spare Tire Stored Underbody w/Crankdown
• Black Front Bumper w/Black Rub Strip/Fascia Accent and 2 Tow Hooks
• Black Rear Step Bumper
• Black Side Windows Trim and Black Front Windshield Trim
• Black Door Handles
• Black Power Heated Side Mirrors w/Convex Spotter, Manual Folding and Turn Signal Indicator
• Manual Extendable Trailer Style Mirrors
• Fixed Rear Window
• Light Tinted Glass
• Variable Intermittent Wipers
• Aluminum Panels
• Black Grille
• Tailgate Rear Cargo Access
• Tailgate/Rear Door Lock Included w/Power Door Locks
• Boxside Steps
• Auto On/Off Reflector Halogen Daytime Running Lights Preference Setting Headlamps w/Delay-Off
• Cargo Lamp w/High Mount Stop Light
• Perimeter/Approach Lights

• Radio: AM/FM Stereo w/MP3 Player -inc: 6 speakers
• Radio w/Seek-Scan, Clock and Speed Compensated Volume Control
• Fixed Antenna
• 6 Speakers
• SYNC 4 w/8" Center Display -inc: wireless phone connection, cloud connected, AppLink w/app catalog, 911 Assist, Apple CarPlay and Android Auto compatibility and digital owner's manual
• Wireless Phone Connectivity
• 2 LCD Monitors In The Front

• 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
• 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
• 60-40 Folding Split-Bench Front Facing Fold-Up Cushion Rear Seat
• Manual Tilt/Telescoping Steering Column
• Power Rear Windows
• Front Cupholder
• Rear Cupholder
• Compass
• Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button
• Cruise Control w/Steering Wheel Controls
• Manual Air Conditioning
• HVAC -inc: Underseat Ducts
• Locking Glove Box
• Interior Trim -inc: Chrome Interior Accents
• Full Cloth Headliner
• Urethane Gear Shifter Material
• HD Vinyl 40/20/40 Split Bench Seat -inc: center armrest, cupholder, storage and driver's side manual lumbar
• Day-Night Rearview Mirror
• Passenger Visor Vanity Mirror
• Full Overhead Console w/Storage and 2 12V DC Power Outlets
• Front And Rear Map Lights
• Full Vinyl/Rubber Floor Covering
• Cab Mounted Cargo Lights
• Smart Device Integration
• Ford Connectivity Package (1-Year Included) -inc: unlimited Wi-Fi hotspot, Included for one-year from warranty start date, Requires activation via Ford app w/credit card authorization; customer may cancel at any time, Evolving technology/cellular networks/vehicle capability may limit functionality and prevent operation of connected features, Ford may temporarily slow data speeds if such data usage reaches or exceeds 50GB within a billing cycle or due to network limitations, If a customer uses more than 50% of their data usage in a roaming country during a 60-day period, Ford may remove or limit the customer's data plan
• Instrument Panel Covered Bin and Dashboard Storage
• Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down
• Delayed Accessory Power
• Power Door Locks w/Autolock Feature
• Driver Information Center
• Trip Computer
• Outside Temp Gauge
• Digital/Analog Appearance
• Seats w/Vinyl Back Material
• Front Center Armrest w/Storage
• Manual Adjustable Front Head Restraints and Manual Adjustable Rear Head Restraints
• Perimeter Alarm
• Securilock Anti-Theft Ignition (pats) Immobilizer
• 2 12V DC Power Outlets
• Air Filtration

• AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
• ABS And Driveline Traction Control
• Side Impact Beams
• Dual Stage Driver And Passenger Seat-Mounted Side Airbags
• Emergency Sos Capability
• Tire Specific Low Tire Pressure Warning
• Safety Canopy System Curtain 1st And 2nd Row Airbags
• Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point and Height Adjusters
• Dual Stage Driver And Passenger Front Airbags
• Rear Child Safety Locks
• Back-Up Camera

ENGINE: 6.7L 4V OHV POWER STROKE V8 TURBO DIESEL B20

• manual push-button engine-exhaust braking and Operator Commanded Regeneration (OCR)
• 190 Amp Alternator (Diesel)
• 34 Gallon Fuel Tank
• GVWR: 11
• 200 lb Payload Package
• 3.31 Axle Ratio
• Dual AGM 68 AH Battery

• Ford Connectivity Package (1-Year Included)
• Internet access capable: 5G Modem - Ford Connectivity Package
• Order Code 610A
• Snow Plow Prep Package
• XL Chrome Package
• 6 Speakers
• AM/FM radio
• Radio: AM/FM Stereo with MP3 Player
• SYNC 4 with 8" Center Display
• Air Conditioning
• Power steering
• Power windows
• Remote keyless entry
• Steering wheel mounted audio controls
• Traction control
• 4-Wheel Disc Brakes
• ABS brakes
• Chrome Front Bumper
• Dual front impact airbags
• Dual front side impact airbags
• Emergency communication system: SYNC 4 911 Assist
• Front anti-roll bar
• Low tire pressure warning
• Overhead airbag
• Brake assist
• Electronic Stability Control
• Exterior Parking Camera Rear
• Delay-off headlights
• Fully automatic headlights
• Halogen Fog Lamps
• Panic alarm
• Security system
• Speed control
• 410 Amp Dual Alternators
• Dual AGM 68 AH Battery
• Engine Block Heater
• Chrome Rear Step Bumper
• Drop-in Bedliner
• Front License Plate Bracket
• Heated door mirrors
• LED Box Lighting
• LED Roof Clearance Lights
• Platform Running Boards
• Power door mirrors
• Rear step bumper
• Turn signal indicator mirrors
• Compass
• Front reading lights
• Illuminated entry
• Outside temperature display
• Overhead console
• Passenger vanity mirror
• Pro Power Onboard - 400W
• Rear reading lights
• Tachometer
• Telescoping steering wheel
• Tilt steering wheel
• Trip computer
• Upfitter Switches (6)
• HD Vinyl 40/20/40 Split Bench Seat
• Split folding rear seat
• Front Center Armrest w/Storage
• Trailer Brake Controller
• 17" Argent Painted Steel Wheels
• Bright Chrome Hub Covers and Center Ornaments
• Power-Sliding Rear-Window with Defrost
• Privacy Glass
• Variably intermittent wipers

• Mileage
• Fuel Economy Est-Combined (MPG): - TBD -
• EPA Fuel Economy Est - City (MPG): - TBD -
• EPA Fuel Economy Est - Hwy (MPG): - TBD -
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 190 & 0
• Maximum Alternator Capacity (amps): 160
• Weight Information
• Base Curb Weight (lbs): 7372
• Base Curb Weight (lbs): 6508
• Gross Axle Wt Rating - Front (lbs): 4400
• Gross Axle Wt Rating - Rear (lbs): 6340
• Curb Weight - Front (lbs): 3845
• Curb Weight - Rear (lbs): 2663
• Gross Vehicle Weight Rating Cap (lbs): 10600
• Gross Combined Wt Rating (lbs): 21000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 14000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1400
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 13800
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3450
• Maximum Trailering Capacity (lbs): 14000
• Suspension
• Suspension Type - Front: Other
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 4400
• Spring Capacity - Rear (lbs): 6340
• Axle Type - Front: Non-Independent
• Axle Type - Rear: Rigid Axle
• Axle Capacity - Front (lbs): 6000
• Axle Capacity - Rear (lbs): 7280
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Brakes
• Brake Type: 4-Wheel Disc
• Brake ABS System: 4-Wheel
• Brake ABS System (Second Line): 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.3
• Rear Brake Rotor Diam x Thickness (in): 14.3
• Tires
• Front Tire Order Code: TD8
• Rear Tire Order Code: TD8
• Front Tire Size: LT245/75SR17
• Rear Tire Size: LT245/75SR17
• Spare Tire Size: Full-Size
• Front Tire Capacity (lbs): 6390
• Rear Tire Capacity (lbs): 6390
• Revolutions/Mile @ 45 mph - Front: 649
• Revolutions/Mile @ 45 mph - Rear: 649
• Wheels
• Front Wheel Size (in): 17 X 7.5
• Rear Wheel Size (in): 17 X 7.5
• Spare Wheel Size (in): Full-Size
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Re-Circulating Ball
• Turning Diameter - Curb to Curb (ft): 53
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Exterior Dimensions
• Wheelbase (in): 160
• Length, Overall (in): 250
• Width, Max w/o mirrors (in): 80
• Height, Overall (in): 81.3
• Overhang, Front (in): 38.2
• Cab to Axle (in): 39.9
• Ground to Top of Load Floor (in): 36.9
• Ground Clearance, Front (in): 8.5
• Ground Clearance, Rear (in): 8.5
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 81.9
• Cargo Box Width @ Top, Rear (in): 66.9
• Cargo Box Width @ Floor (in): 66.9
• Cargo Box Width @ Wheelhousings (in): 50.5
• Cargo Box (Area) Height (in): 21.1
• Tailgate Width (in): 60.5
• Cargo Volume (ft³): 65.4
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.8
• Front Leg Room (in): 43.9
• Front Shoulder Room (in): 66.7
• Front Hip Room (in): 62.5
• Second Head Room (in): 40.4
• Second Leg Room (in): 43.6
• Second Shoulder Room (in): 65.9
• Second Hip Room (in): 64.7
• Summary
• Vehicle Name: Ford Super Duty F-350 SRW
• Body Style: SD Crew Cab
• Body Code: T
• Emissions
• Tons/yr of CO2 Emissions @ 15K mi/year: - TBD -
